SF/R系列 15A 250V 77°C/229°C 溫度保險絲,使用有機熱敏熱元件的不可重設熱熔斷器,符合RoHS 和REACH 標準,更高的 Tm 等級,由於其形狀和尺寸小,對溫升非常敏感,採用樹脂密封,可靠性高、精準度高,適用於大電流的電流
全店,滿千郵寄超商純取免運優惠
商品存貨不足,未能加入購物車
您所填寫的商品數量超過庫存
{{'products.quick_cart.out_of_number_hint'| translate}}
{{'product.preorder_limit.hint'| translate}}
每筆訂單限購 {{ product.max_order_quantity }} 件
現庫存只剩下 {{ quantityOfStock }} 件
• 使用有機熱敏熱元件的不可重設熱熔斷器
• 較小的保險絲體
• 符合RoHS 和REACH 標準
• 更高的 Tm 等級
• 由於其形狀和尺寸小,對溫升非常敏感
• 採用樹脂密封,可靠性高、精準度高
• 適用於大電流的電流
Part Number | Rated Functioning Temperature Tf (°C) | Cut-off Temperature (Functioning Temperature) (°C) | Maximum Temperature Limit Tm (°C) | Holding Temperature Th Tc (°C) | Electrical Ratings |
SF 76R0 | 77 | 76 +0, - 4 | 165 | 62 | 15A 250VAC |
SF 229R0 | 229 | 227 ± 2 | 380 | 200 |
型號標示「R0」為標準引線長度。 引線長度較長的型號變更為 SF**R1。
規格 | 產品貨號 | 區號 | 品牌 | 原廠貨號 |
77℃ | 3680111000723 | Lb10-01 | NEC | SF76R0 |
229℃ | 3680111000846 | Lb09-02 | SF229R1 |
