STM32F030C6T6

• Core: Arm® 32-bit Cortex®-M0 CPU, frequency up to 48 MHz
• Memories
  – 16 to 256 Kbytes of Flash memory
  – 4 to 32 Kbytes of SRAM with HW parity

• CRC calculation unit
• Reset and power management
  – Digital & I/Os supply: VDD = 2.4 V to 3.6 V
  – Analog supply: VDDA = VDD to 3.6 V
  – Power-on/Power down reset (POR/PDR)
  – Low power modes: Sleep, Stop, Standby

• Clock management
  – 4 to 32 MHz crystal oscillator
  – 32 kHz oscillator for RTC with calibration
  – Internal 8 MHz RC with x6 PLL option
  – Internal 40 kHz RC oscillator

• Up to 55 fast I/Os
  – All mappable on external interrupt vectors
  – Up to 55 I/Os with 5V tolerant capability

• 5-channel DMA controller
• One 12-bit, 1.0 µs ADC (up to 16 channels)
  – Conversion range: 0 to 3.6 V
  – Separate analog supply: 2.4 V to 3.6 V

• Calendar RTC with alarm and periodic wakeup from Stop/Standby
• 11 timers
  – One 16-bit advanced-control timer for six-channel PWM output
  – Up to seven 16-bit timers, with up to four IC/OC, OCN, usable for IR control decoding
  – Independent and system watchdog timers
  – SysTick timerr

• Communication interfaces
  – Up to two I2C interfaces
  – Fast Mode Plus (1 Mbit/s) support on one or two I/Fs, with 20 mA current sink
  – SMBus/PMBus support (on single I/F)
  – Up to six USARTs supporting master synchronous SPI and modem control; one with auto baud rate detection
  – Up to two SPIs (18 Mbit/s) with 4 to 16 programmable bit frames

• Serial wire debug (SWD)
• All packages ECOPACK®2

1. TIM15 is not present.
2. TIM7 is not present.
3. SPI2 is not present.
4. I2C2 is not present.
5. USART2 to USART6 are not present.
6. USART3 to USART6 are not present

• STM32F030C6T6 x 1
