產品貨號:368010102008
區號:Ma06-33,Kc04-03-E01-07
品牌:
原廠貨號:
全店,滿千郵寄超商純取免運優惠
商品存貨不足,未能加入購物車
您所填寫的商品數量超過庫存
{{'products.quick_cart.out_of_number_hint'| translate}}
{{'product.preorder_limit.hint'| translate}}
每筆訂單限購 {{ product.max_order_quantity }} 件
現庫存只剩下 {{ quantityOfStock }} 件
商品簡介 |
商品屬性 | 屬性值 |
RoHS | 詳細資料 |
技術: | Si |
通道數: | 1 Channel |
晶體管極性: | N-Channel |
Vds - 漏-源擊穿電壓: | 20 V |
Id - C連續漏極電流: | 3.9 A |
Rds On - 漏-源電阻: | 31 mOhms |
Vgs th - 門源門限電壓 : | 450 mV |
Vgs - 閘極-源極電壓: | 4.5 V |
Qg - 閘極充電: | 7.5 nC |
最低工作溫度: | - 55 C |
最高工作溫度: | + 150 C |
Pd - 功率消耗 : | 0.75 W |
配置: | Single |
通道模式: | Enhancement |
高度: | 1.45 mm |
長度: | 2.9 mm |
系列: | SI2 |
晶體管類型: | 1 N-Channel |
寬度: | 1.6 mm |
互導 - 最小值: | 30 S |
下降時間: | 10 ns |
上升時間: | 30 ns |
標準斷開延遲時間: | 35 ns |
標準開啟延遲時間: | 9 ns |
每件重量: | 8 mg |
