產品貨號:368031700005
區號:
品牌:Waveshare
原廠貨號:9085
全店,滿千郵寄超商純取免運優惠
商品存貨不足,未能加入購物車
您所填寫的商品數量超過庫存
{{'products.quick_cart.out_of_number_hint'| translate}}
{{'product.preorder_limit.hint'| translate}}
每筆訂單限購 {{ product.max_order_quantity }} 件
現庫存只剩下 {{ quantityOfStock }} 件
商品簡介 |
可視角度>160° Raspberry/Jetson Nano/Arduino/STM32等平台
3/4 SPI介面 I2C介面 彎排針
商品應用:
商品規格 |
工作電壓 | 3.3V / 5V |
通訊介面 | 3-wire SPI、4-wire SPI、I2C |
驅動晶片 | SSD1306 |
顯示顏色 | 黃藍雙色 |
解析度 | 128 x 64 pixels |
顯示尺寸 | 0.96 吋 |
可視角度 | >160 ° |
工作溫度 | -20°C~70 °C |
儲存溫度 | -30°C~80 °C |
SPI 控制介面
功能引腳 | 描述 |
VCC | 電源正(3.3~5V電源輸入) |
GND | 電源地 |
NC | NC |
DIN | 模組資料輸入 |
CLK | 模組時鐘信號輸入 |
CS | 模組片選信號,低電壓有效 |
D/C | 模組命令信號,低電壓表示命令,高電壓表示資料 |
RES | 模組重啟信號,低電壓有效 |
硬體配置 | |||
模式 / 標誌 | BS0 / BS1 | DIN | SCK |
3-wire SPI | 1/0 | MOSI | SCLK |
4-wire SPI | 0/0 | MOSI | SCLK |
I2C | 0/1 | SDA | SCL |
文件下載 |
出貨清單 |
